16 km of Aramid 8 Cable (8 SM G.652.D Fibers, Aramid Reinforced) with a Selected Prize for 0.25 EUR

CDR / Sets with prizes

16 km of Aramid 8 Cable (8 SM G.652.D Fibers, Aramid Reinforced) with a Selected Prize for 0.25 EUR

Brand: ZTT

Product Code: OP-AZXOTKTCDD8-PROM

Catalog number: 10514

Warranty (months):

Price

2 719,23 €

3 344,65 € incl. tax

favoriteAdd to wishlist

Description

Promotional Bundle
By purchasing the set below, you pay for 16 km of Aramid 8J cable and can choose a prize that will be invoiced for just 1 PLN net! Available options: Xiaomi Scooter 4 Lite electric scooter, Xiaomi Vacuum X20+ vacuum cleaner, Philips LatteGo EP2334/10 coffee machine, or DJI Mini 4K drone!
ZTT cables can be freely combined – for example, you can choose 4 km of Glass 8J cable, 4 km of Glass 12J cable, and 8 km of Aramid 24J cable. If you'd like to modify the set, please contact our customer service office.

Purchase information

Shipping on a pallet

The cable is originally wound on a roll of 4 km - there is the possibility of rewinding (a smaller section of the cable on another roll), the cost of the rewinding (the drum is included): 25 €

ZTT Aramid Z-XOTKtcdD is an universal fiber optic cable with 8 fibers G.652.D. The fibers are located in one central tube with 2 mm of diameter. The construction was reinforced by numerous fibers aramid, thanks to that the cable is distinguished by hightensile strength - up to 600 N (installation strength: 1200 N). Two rods ARP or FRP with 0,5 mm of diameter make another reinforcement.

The external cover was made out of high quality HDPE, its nominal largeness is of 1,4 mm. The optical fibre is totally non-conducting. The cable can be used in teletechnical canalization or in aerial installations. Maximal arc in aerial installations can be of 50 m.

The product is of small diameter (+- 5,3 mm) and weight (+- 22 kg/km), but at the same time it's really resistant and strong.

Suggestes slings:

2.1 PA (35 200)
2.3

The most important features:

8 fibers G.652.D;
one, central tube
universal cable;
cable can be used in teletechnical canalization or aerial installations;
more or less 5,3 mm of diameter;
maximal arc: 50 m;
tensile strength: up to 600 N (temporary 1200 N);
aramid reinforcement;
2 rods ARP or FRP.

Details

Aramid Z-XOTKTcdD 8 fibers
Number of tubes	1 central tube
Diameter of the tube	2 mm
Type of fiber	G.652.D
Gel	Thixotropic gel
The main elements of reinforcement	2 rods ARP or FRP
The diameter of rod ARP / FRP	0,5 mm
Other reinforcement	Aramid fibers
Substance of the external cover	HDPE
Colour of the external cover	Black
Largenes off the external cover	More or less 1,4 mm (± 5%)
Ripcords	2
Diameter of the cable	~ 5,3 mm (± 5%)
Weight of the cable	~ 22 kg/km (± 5%)
Tensile strength	Continuous: 600 N During the installation: 1200 N
Beam of bending	During the installation: 20 x the diameter After the installation: 10 x the diameter
Acceptable temperature of application	From -30 to 70 C
