0,25 € netto
Solarix SXKD-8-SSTP-LSOH SSTP cat. 8 LSZH Cca-s1,d2,a1 500m
Price
557,47 €
685,69 € incl. tax
favoriteAdd to wishlist
Installation Cable Solarix Category 8 SSTP LSOH Cca s1 d2 a1 2000 MHz
The Solarix double shielded installation cables comply with the most stringent structured cabling specifications. They easyily exceed the requirements specified in the ANSI/TIA 568 and ISO/IEC 11801 standards for Category 8 / Class I cables. Selected design of these cables goes hand-in-hand with the best quality which, with strictly controlled production, guarantees the highest performance. The Solarix Category 8 installation cables are produced in S-STP configuration and are tested up to 2000 MHz. Their excellent performance ensures full compatiblity with all new high-speed data protocols, such as 40GBASE-T and 25GBASE-T. Foamed PE insulated conductors have the pairs shielded by aluminioum foil and sopper braid. Sheath material is supported by fire retardant, low smoke, halogen free, and CPR rated compunds - LSOH (reaction to fire Cca s1 d2 a1).
Specification
| SXKD-8-SSTP-LSOHFR | |
| LSOH Sheath | Reaction to fire Cca s1 d2 a1 |
| Applicable Standards | ISO/IEC 11801, IEC 61156-5, EN 50173-1, EN 50173-2, EN 50288-12-1 |
| Conductor Type and Size | Bare copper wire 0.596 mm ± 0.005 mm |
| Insulation | Skin-foam-skin PE |
| Wire Diameter with Insulation | 1,45 mm |
| Cable Diameter | 8 mm |
| Weight | 75,4 kg/km |
| Colour | Orange RAL 2003 |
| NVP | 79% |
| Propagation delay | 535 ns/100 m |
| Delay skew | ≤ 45 ns/100 m |
| Storage Temperature | -20 to +60 °C |
| Operation Temperature | -20 to +60 °C |
| Installation Temperature | 0 to +50 °C |
| Installation Cables Transmission Characteristics (at 20°C) | |||||||
| f (MHz) | Attentuation (dB/100m) | NEXT (dB) | PSNEXT (ns/100m) | Prop. delay (ns/100m) | ACR-F (dB/100m) | PSACR-F (dB/100m) | Return loss (dB) |
|---|---|---|---|---|---|---|---|
| 1 | 0,50 | 90,00 | 87,00 | 485 | 88,00 | 85,00 | 24,00 |
| 4 | 1,00 | 80,30 | 79,20 | 469 | 79,30 | 77,90 | 26,00 |
| 10 | 1,60 | 75,00 | 73,70 | 463 | 71,90 | 70,10 | 26,00 |
| 16 | 2,10 | 77,10 | 74,60 | 461 | 67,70 | 66,90 | 30,00 |
| 20 | 2,30 | 76,40 | 73,80 | 460 | 65,70 | 64,50 | 30,00 |
| 25 | 2,60 | 77,90 | 77,00 | 459 | 64,40 | 62,80 | 28,00 |
| 31,25 | ,90 | 77,90 | 77,00 | 459 | 64,40 | 62,80 | 28,00 |
| 62,5 | 4,20 | 71,40 | 70,90 | 457 | 56,80 | 55,00 | 27,00 |
| 100 | 5,40 | 65,70 | 64,90 | 456 | 54,00 | 51,50 | 27,00 |
| 200 | 7,70 | 67,50 | 64,40 | 455 | 46,20 | 45,50 | 26,00 |
| 250 | 8,70 | 67,50 | 64,70 | 454 | 42,90 | 43,90 | 25,50 |
| 300 | 9,60 | 63,40 | 61,10 | 454 | 39,70 | 39,00 | 25,00 |
| 400 | 11,20 | 57,40 | 56,30 | 453 | 40,90 | 39,20 | 24,00 |
| 500 | 12,60 | 60,60 | 58,70 | 453 | 37,30 | 34,40 | 23,00 |
| 600 | 14,10 | 63,30 | 61,90 | 452 | 32,80 | 31,00 | 22,00 |
| 1000 | 19,20 | 60,90 | 58,20 | 451 | 28,90 | 28,10 | 20,00 |
| 1500 | 22,70 | 53,30 | 50,40 | 452 | 21,60 | 21,40 | 18,00 |
| 2000 | 28,10 | 41,00 | 38,60 | 452 | 19,20 | 17,40 | 16,00 |
